FLIR GF306 Gasmyndavél




The FLIR GF306 optical gas imaging camera visualizes sulfur hexafluoride (SF6) and other gas emissions without the need to shut down operations. SF6 is used in the electric power industry as an insulator and quenching medium for gas-insulated substations and circuit breakers. The portable, non-contact GF306 allows you to quickly scan substations for leaks while maintaining a safe distance from high-voltage equipment. By catching leaks early, the GF306 reduces lost revenue to breakdowns and repairs.

Detector Type   Focal plane array, cooled QWIP

Dynamic Range 14-bit, Real-time non-radiometric recording: MPEG4/H.264 (up to 60 min./clip) to memory card3

Mounting           UNC 1/4″-20

Packaging Size  400 x 190 x 510 mm (15.7 x 7.5 x 20.1 in.)

Power  AC adapter 90-260 VAC, 50/60 Hz or 12 V from a vehicle

Spectral Range 10.3 – 10.7 µm

Weight [incl lens & batteries]    2.48 kg (5.47 lb.)

Zoom    1-8x continuous, digital zoom

Size [L x W x H ] w Lens 305 × 169 × 161 mm (12.0 × 6.7 × 6.3 in.)


Storage Media  Removable SD or SDHC memory card; two card slots


Encapsulation   IP 54 (IEC 60529)

Operating Temperature Range  –20°C to 40°C (–4°F to 104°F)

Storage Temperature Range      –30°C to 60°C (–22°F to 140°F)


Camera Control Remote camera control via USB

Camera f-number           f/1.5

Color palettes   Iron, Gray, Rainbow, Arctic, Lava, Rainbow HC

Detector Pitch   30 µm

Field of View     14.5° × 10.8°

Focus    Automatic (one touch) or manual (electric or on the lens)

Frame Rate [Full Window]           60 Hz

Global Positioning System [GPS]              Location data stored with every image

Image Modes    IR image, visual image, High Sensitivity Mode (HSM)

Menu Commands           Level/span, auto adjust continuous/manual/semi-automatic, zoom, palette, start/stop recording, store image, playback/recall image

Resolution          320 x 240 pixels

Sensor Cooling  Stirling Microcooler (FLIR MC-3)

On Camera Display          Built-in widescreen, 4.3 in. LCD, 800 x 480 pixels

Video Recording & Streaming    Real-time non-radiometric streaming: RTP/MPEG4

Visual Image      3.2 MP from integrated visible camera

Visual Video      MPEG4 (25 min./clip) to memory card


Accuracy             ±1°C (±1.8°F) for temperature range (0°C to 100°C, 32°F to 212°F) or ±2% of reading for temperature range (>100°C, >212°F)

NETD     < 15 mK @ 30°C (86°F)

Temperature Range       –40°C to 500°C (–40°F to 932°F)

Automatic Gain Control Continuous/manual, linear, histogram

Bump/Vibration               25 g (IEC 60068-2-27) / 2 g (IEC 60068-2-6)


Battery System Rechargeable Li-ion battery


Image Storage Capacity > 1200 images (JPEG) with post-process capability per GB on memory card
